1GE+1FE+WiFi+CATV GPON ONU
1*10/100M and 1*10/100/1000M Ethernet interface,CATV, 1 GPON interface, support Wi-Fi function, external power supply adapter
Product Model |
BD-ONU-802RWT-G |
Technical item |
1GE+1FE+WiFi+CATV |
Typical Solution |
FTTH,FTTO,PON+EOC |
Typical Business |
INTERNET, IPTV, VOD, IP Camera, WIFI |
Power supply |
DC 12V/1A |
Wireless |
Compliant with IEEE802.11b/g/n, 300Mbps, 2T2R |
Wavelength |
Tx1310nm, Rx 1490nm, CATV 1550nm. |
RF interface |
1 RF output interface |
PON interface |
1 GPON connector, SC single-mode/single-fiber, downlink/uplink 1.25Gbps. |
1GE 1FE GPON ONU CATV features 1 PON port, 1 10/100BASE-T port, 1 10/100/1000BASE-T port, 1 CATV port, and WiFi.
The GPON ONU CATV is mostly used in FTTH and FTTO applications. The GPON WiFi ONU supports the 1000Base-PX20+ standard, which has a maximum optical splitting ratio of 1:64 and a distance of 20 kilometers, as well as 1GE 1FE. Working together, the GPON ONU and the OLT may provide a flexible network structure and maintenance, as well as provide entire FTTx solutions.
Functions
Data Service Functions
► Full speed non-blocking switching.
► 2K MAC address table.
► 64 full range VLAN ID.
► Support QinQ VLAN, 1:1 VLAN, VLAN reusing, VLAN trunk, etc.
► Integrated port monitoring, port mirroring, port rate limiting, port SLA, etc.
► Support auto polarity detection of Ethernet ports (AUTO MDIX).
► Integrated IEEE802.1p QoS with four level priority queues.
► Support IPv4 IGMP snooping and IPv6 MLD snooping.
► Support bridge, router and bridge/router mixed mode.
WIFI Service Functions
► Integrated 802.11b/g/n, 300Mbps, 2T2R.
► Support 128 connections.
► Support WEP and WPA/WPA2 security protocols.
CATV Service Functions
► RF frequency: 45~875MHz.
► Turn on/off RF output remotely.
► RF level can be showed on PC Web real time.
► AGC Dynamic Range (dBm) :-6~+2
► RF Output Level(dBuv):80
Specification
Technical item |
1GE+1FE+WiFi+CATV |
PON interface |
1 GPON connector, SC single-mode/single-fiber, downlink/uplink 1.25Gbps. |
Wavelength |
Tx1310nm, Rx 1490nm, CATV 1550nm. |
Optical interface |
1 PON interface, 1 CATV interface, SC connector |
LAN interface |
1x 10/100/1000Mbps auto adaptive Ethernet interfaces and 1x 10/100M Full/Half. RJ45 connector. |
RF interface |
1 RF output interface. |
Wireless |
Compliant with IEEE802.11b/g/n, 300Mbps, 2T2R. |
LED |
7, For Status of POWER, LOS, REG, GE, FE, CATV and WiFi. |
Operating condition |
Temperature: -5℃~55℃Humidity: 10%~90%(non-condensing) |
Storing condition |
Temperature :-30℃~60℃Humidity :10%~90%(non-condensing) |
Power supply |
DC 12V/1A |
Power consumption |
≤8W |
Dimension |
158mm×115mm×33mm(L×W×H) |
Net weight |
0.4Kg |
Technical item
|
1GE+1FE+WiFi+CATV
|
PON interface
|
1 GPON connector, SC single-mode/single-fiber, downlink/uplink 1.25Gbps.
|
Wavelength
|
Tx1310nm, Rx 1490nm, CATV 1550nm.
|
Optical interface
|
1 PON interface, 1 CATV interface, SC connector
|
LAN interface
|
1x 10/100/1000Mbps auto adaptive Ethernet interfaces and 1x 10/100M Full/Half. RJ45 connector.
|
RF interface
|
1 RF output interface.
|
Wireless
|
Compliant with IEEE802.11b/g/n, 300Mbps, 2T2R.
|
LED
|
7, For Status of POWER, LOS, REG, GE, FE, CATV and WiFi.
|
Operating condition
|
Temperature: -5℃~55℃
Humidity: 10%~90%(non-condensing)
|
Storing condition
|
Temperature :-30℃~60℃
Humidity :10%~90%(non-condensing)
|
Power supply
|
DC 12V/1A
|
Power consumption
|
≤8W
|
Dimension
|
158mm×115mm×33mm(L×W×H)
|
Net weight
|
0.4Kg
|
Application
Typical Solution:FTTH,FTTO,PON+EOC
Typical Business:INTERNET, IPTV, VOD, IP Camera, WIFI
Order Information
Product Model |
Descriptions |
Inquiry |
BD-ONU-802RWT-G |
1GE+1FE+WiFi+CATV GPON, 1*10/100M and 1*10/100/1000M Ethernet interface,CATV,1 GPON interface, support Wi-Fi function, external power supply adapter |
